Semi automatic bagging machine
Semi automatic bagging machine
Semi automatic bagging machine

Semi automatic bagging machine

Get Latest Price
Min. Order:1
Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Balanced counterweight type front and rear flipping bagging machine
Station driving 360 ° rotating clamping machine operation video
Product Description

Semi-Automatic Bagging Machine for Clamping Applications

(Also available as: Automatic Bagging Solution for Clamping Machines; Compact Semi-Automatic Bagging Equipment)

Precision Bagging with Secure Clamping Technology

Our advanced bagging systems deliver reliable packaging performance for industrial applications. Featuring reinforced hydraulic cylinders ensuring a tight, secure grip on various bag types and materials.

Key Features:

✔ Semi-automatic operation – Balanced efficiency & control

✔ Heavy-duty clamping mechanism – Consistent pressure up to 5,000N

✔ Compact footprint – Saves valuable floor space

✔ Customizable configurations – Adapts to your specific products


Project/Lesson Organization LYCTS-JB
Basic parameters Rated lifting capacity KG 200/500/1000
Increase the height MM 1600/2000/2500/3000
Power form   Battery
The height of the gantry crane after lifting MM 2080/2580/3080/3580
Minimum turning radius MM 1950
Minimum channel requirement MM 2600
Dimensions of the shape Overall length of the vehicle (excluding fixtures)   1850
Overall width of the vehicle body MM 850
Clamp diameter MM Optional
Rotation 90/180/360
Main performance characteristics Driving speed (loaded/unloaded) KM/H 3/5
Acceleration rate (loaded / unloaded) MM/S 90/125
Maximum climbing gradient (loaded / unloaded) % 3/5
Braking method   Ground brake
Wheel Tire material   Polyurethane
Front wheel size MM 80*70
Balance wheel MM 100*35
Drive wheel MM -
Motor Enhanced motor KW 2.2
Drive motor KW -
Battery (Voltage/Power) V/AH 12/120AH
