Heavy-Duty Dump Truck for Industrial Material Transport
Engineered for efficient loading and hauling of heavy bulk materials.
Robust construction ensures reliable performance in demanding industrial settings.
Customization options available to meet specific operational requirements. (Total characters: 298)
| Basic parameters | Rated lifting capacity (kg) | 2000 - 5000 options available |
| Lifting height of the gantry (mm) | Optional | |
| Center of load distance (mm) | 900 | |
| Steering system | Mechanical steering | |
| Minimum clearance from the ground of the fork (mm) | ≤470 | |
| Dimensions of the shape | Static height of the gantry (mm) | |
| Overall length of the vehicle (with pedals retracted) (m) | 2530 | |
| Overall width of the vehicle (m) | 880 | |
| Width of the fork (in millimeters) | Optional | |
| Load lug dimensions (length/width/height/) meters | 1750X135X100 (as per requirements) | |
| Speed increase (loaded/unloaded) (m/min) | 50/100 | |
| Wheel | Driving speed (loaded / unloaded) (km/h) | 4.5/5.5 |
| Front wheel size (mm) | 200X80 | |
| Balance wheel size (mm) | 125*50 | |
| Control mode | Standing position | |
| Speed control method | MOS | |
| Braking method | Electromagnetic braking | |
| Battery rated voltage/(v/ah) | Combined battery: 24V, 210ah | |
| Frame material: (Manganese steel H-shaped steel) | Special steel for forklift mast | |
| Kinetic energy configuration | Enhanced motor (2.2ku) | Liefurt |
| Drive motor (1.5kW) | Renewable energy | |
| Controller | Curtis 1207 | |
| Charger | 24V 30A | |
| Basic configuration | Sealing ring | Taiwan Speedbid |
| Cylinder (Double cylinder) | Toppon | |
| High-pressure oil pipe | Jiangsu Shenlong | |
| Hydraulic oil | Shanghai No. 46 | |
| Bearings | Harbin | |
| Front and rear wheels | Yantai, Shandong Province | |
| Other preparations | Jiangsu Luyuan | |
| The total weight of the machine is approximately... | 1500 | |
| The above parameters are for reference only. The manufacturer reserves the right to modify the parameters according to actual needs. | ||
