Steering balance fully automatic bagging machine
Steering balance fully automatic bagging machine
Steering balance fully automatic bagging machine

Steering balance fully automatic bagging machine

Get Latest Price
Min. Order:1
Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Station driving 360 ° rotating clamping machine operation video
Balanced counterweight type front and rear flipping bagging machine
Product Description
Automatic Clamping machine for steering balance
Fully automatic bagging system for steering parts
High speed automatic bagging for steering units
High-strength steel portal frame, safe and stable
Arc-shaped ground contact, energy saving and efficiency improvement
Project/Lesson   Organization LYCPDZ-JB
Basic parameters Rated lifting capacity KG 200/500/1000
Increase height MM 1600/2000/2500/3000
动力形式   Battery
Power form MM 2080/2580/3080/3580
Minimum turning radius MM 1950
Minimum channel requirement MM 2600
Dimensions (of the shape) Overall length of the vehicle (excluding fixtures)   1850
Overall width of the vehicle body MM 850
Clamp diameter MM Optional
Rotation   90/180/360
Main performance characteristics Driving speed (loaded/unloaded) KM/H 3/5
Acceleration rate (loaded / unloaded) MM/S 90/125
Maximum slope gradient (loaded/unloaded) % 3/5
Braking method   Electromagnetic braking
Wheel Tire material   Polyurethane
Front wheel size MM 200*85
Balance wheel MM 156*75
Drive wheel MM 250*80
Motor Enhanced motor KW 2.2
Drive motor KW 1.5
Battery (Voltage/Charge) V/AH 12V*4/52AH
The above parameters are for reference only. Customization can be carried out according to actual needs. The factory reserves the right to modify the materials and actual required parameters.
