| Basic parameters | Product model | LYCPD | ||
| 2 | Drive form | Electric | ||
| 3 | Driving method | Sitting-type | ||
| 4 | Rated load | kg | 2000/(optional) | |
| 5 | Load center | mm | 450 | |
| 6 | Wheelbase | mm | 1140 | |
| 7 | Forward/backward inclination angle | 6°/12° | ||
| 8 | Self-respect | kg | 3200 | |
| Wheel | 1 | Tire | Solid tire | |
| 2 | Front wheel size | 18×6×121/8 | ||
| 3 | Rear wheel size | 310*100 | ||
| 4 | Number of wheels (front/rear) | 2x2 | ||
| 5 | Front wheel spacing | mm | 860 | |
| 6 | Rear wheel spacing | mm | 200 | |
| Basic dimensions | 1 | Overall length | mm | 2635 |
| 2 | Overall width | mm | 1020 | |
| 3 | Overall height (when the fork is at its lowest position) | mm | 2100 | |
| 4 | Overall height (when the fork is at its highest position) | mm | 3830 | |
| 5 | Lifting height | mm | 3000 | |
| 6 | Height of the roof support frame | mm | 1950 | |
| 7 | Front suspension distance | mm | 370 | |
| 8 | Clamping fixture opening | mm | Optional | |
| 9 | Fixture height | mm | According to actual needs | |
| 10 | Is the fixture rotating? | mm | According to the requirements | |
| 11 | "Width of the right-angle stacking passage, pallet 1000x1200 (1200 along the edge of the forklift)" | mm | 3050 | |
| 12 | Turning radius | mm | 1750 | |
| Performance | 1 | Driving speed: Loaded / Empty | km/h | 10/11 |
| 2 | Increase speed, loaded / unloaded | mm/s | 200/280 | |
| 3 | Maximum climbing capacity: Loaded / Empty | % | 15% | |
| Motor | Drive motor power | kw | 4 | |
| 2 | Increase the power of the motor | kw | 4 | |
| 3 | Battery voltage / capacity | V/Ah | 4×12V/150 | |
| 4 | Control method | AC | ||
| The bagging machine can be customized according to the required bagging weight. The above parameters are for reference only. The factory reserves the right to modify the parameters based on actual needs. | ||||
